MCH Modules


For years, cooler-heaters have been made with a "one size fits all" approach that limits customization and often adds unnecessary cost. That's why CardioQuip created the MCH Series to be modular in design.  Customize your MCH unit with the modules below to fit your specific needs.




Available MCH-1000(i) Modules & Accessories

2018 Refrigeration Module small.png

Refrigeration Module  |  MCH-10RMS

Tired of hauling ice buckets to the OR? The CardioQuip Refrigeration Module replaces the lid on the MCH-1000(i) with an enclosed condensing unit that forms a block of ice in the tank. With room-temperature water, the Refrigeration Module will chill the water to 3°C in about one hour, and begin to form ice in about 90 minutes.  Click here for a timelapse video.


2018 CPG angle small.png

Cardioplegia Shared Channel (CSC) Module  |  MCH-10CSC

With the Cardioplegia Shared Channel Module, there's no need to add an additional unit for Cardioplegia. In the dual-shared channel arrangement, the main circuit delivers fully temperature-controlled water, and the secondary unit can be toggled between cold water (directly from the ice tank) and the main circuit. The Cardioplegia Shared Channel module is a perfect complement to the Quest MPS™, increasing the cooling capacity of that system.


2018 DAM hose small.png

Dripless Anti-Microbial (DAM) Hose Kit  |  MCH-10DMX

In today's perfusion climate, maintaining water quality in the OR is critical. We introduced the Dripless Anti-Microbial Hose Kit to offer a clean and safe way to keep cooler-heater water away from the OR environment. Dripless Connectors at both ends prevent water leakage and Silver-impregnated antimicrobial PVC tubing resists biofilm formation.


Blanket Connection Module

Working with a patient blanket? Add the Blanket Connection Module to your MCH-1000(i) to provide external warming or cooling. Applications include prevention and treatment of hypothermia, fever reduction, and general patient comfort.




Available MCH-1000(m) Modules & Accessories

2018 Minicart with m WEB.png

MiniCart  |  MIN-11CRT

CardioQuip's lightweight stainless steel MiniCart is designed to increase the portability of your MCH-1000(m) compact unit. The MiniCart is fully customizable to suit your specific needs.

  • Fully adjustable sliding shelf that locks into place
  • Medical Grade Casters
  • Dual Adjustable height infusion poles
  • Small footprint, easy to maneuver
  • Customized to fit MCH-1000(m)
  • Made in the USA

TEC lid.png

Thermoelectric Cooling (TEC) Lid Module  |  MCH-11TEC

Want to prolong the life of your ice? The Thermoelectric Cooling (TEC) Lid Module replaces the lid on the MCH-1000(m) and provides 100W of thermoelectric cooling power.


Wheelset Option  |  MCH-11WSO

Need to move your mini around? Add portability to the MCH-1000(m) with the Wheelset Option module. The wheelset option features fully lockable medical grade casters mounted on a stainless steel frame.


2018 DAM hose small.png

Dripless Anti-Microbial (DAM) Hose Kit  |  MCH-11DMX

In today's perfusion climate, maintaining water quality in the OR is critical. We introduced the Dripless Anti-Microbial Hose Kit to offer a clean and safe way to keep cooler-heater water away from the OR environment. Dripless Connectors at both ends prevent water leakage and Silver-impregnated antimicrobial PVC tubing resists biofilm formation.
